U.S. Solid

200 x 0.001g Analytical Balance, 1mg Lab Balance Digital Precision Scale

200 x 0.001g Analytical Balance, 1mg Lab Balance Digital Precision Scale

SKU: Product SKU: JFDBS00015-200G

Low stock: 10 left

Regular price $229.27 USD
Regular price Sale price $229.27 USD
Sale Sold out
Shipping calculated at checkout.
 More payment options
View full details
Responsive Page with Multiple Modules Desktop Image 1 Desktop Image 2

Introduction

The USS-DBS15 series delivers high accuracy with a precision of 0.001g, ensuring reliable and precise measurements for a variety of weighing tasks. Designed for ease of use and quick response, it features a clear single display screen and an RS232 interface for seamless data transfer. Ideal for laboratory and industrial applications, this balance combines performance and simplicity for efficient weighing operations.

Applications

Desktop Image 1 Desktop Image 2

Features

  • Readability: 0.001g with strain gauge
  • Capacity:20mg-200g
  • Stabilization Time: ≤1.5 seconds
  • External Calibration: Manual calibration with weights
  • 5 Weighing Units Conversion: oz, ct, g, ozt, lb
  • RS232 Interface: Enables connection to a printer or a computer for data transfer.
  • Built-in Applications: Piece counting function, tare function, over load protection, memory for accumulated time and etc.

More Details

Desktop Image 1 Desktop Image 2

User Manual

To learn how to install, calibrate, set up, and use this product, please refer to the user manual.

Packing List

Balance Main Body Power Cable
Calibration Weight (100g) Instruction Manual

*To view the full table on mobile, please swipe left or right on the screen.

Technical Data

Model USS-DBS15-2 Working Temperature 41℉-104℉
Weighing Sensor Strain gauge Stabilization Time ≤1.5s
Calibration External calibration Calibration Weight 100g*1
Capacity 20mg-200 g Units oz, ct, g, ozt, lb
Readability 0.001g Interface RS232
Repeatability ±0.002g Power AC110-240V 50/60Hz
Linearity ±0.002g Packaging Dimensions 14.17"x10.63"x13.78"
Pan Size Φ90 mm Gross Weight 8.38 lbs
Number of Displays 1 Windshield Yes

*To view the full table on mobile, please swipe left or right on the screen.

Precautions

  • Leveling the Balance: Accurate horizontal positioning necessary for repeatable measurementsand exact results. Adjust the leveling feet of the analytical balance until the air bubbleinthe indicator is centered.
  • Warm-Up Requirement: For accurate results, the balance must warm up for at least 30 minutes after being powered on or after a power outage longer than 30 minutes, to reach the proper operating temperature before calibration or use.(For warm-up time details, refer to the user manual or contact support.)
  • Stability: Place the balance on a stable, vibration-free surface, away from drafts and electromagnetic interference. It's important to note that high-precision balances are more susceptible to environmental factors, which can affect reading stability.
  • Calibration: Calibrate the balance if it is moved (even within the same room), when ambient conditions change, and before each use. If pressing the "CAL" button has no effect, ensure you are pressing and holding it. For most models, calibration requires a long press rather than a quick tap.(Refer to the manual for specific instructions).

Troubleshooting

Problem Cause Solution
Upper Line "horizontal line" Over Load Re-calibrate
Under Line "horizontal line" Overload or load cell broken Re-calibrate
Display shows "Err-1" Too frequently turn on and off the balance Turn off the balance, resume it after 3 seconds
Display shows "Err-2" The balance is not stabilized Recalibrate machine make sure balance is level, and make sure item being weighed is fully stable.

*To view the full table on mobile, please swipe left or right on the screen.

All Options

Units Readability Model Capacity Calibration Weight Repeatability Linearity Calibration Interface Stabilization Time Pan Size Power Supply
5 types 0.001g USS-DBS15-1 20mg-100g 50g*1 ±0.002g ±0.002g External calibration RS232 ≤1.5s Φ90mm AC100-240V
USS-DBS15-2 20mg-200g 100g*1
USS-DBS15-3 20mg-300g 200g*1
USS-DBS15-5 20mg-500g 500g*1 ±0.005g ±0.005g
* 5 Weighing Units Conversion: oz,ct,g,ozt,lb
