A.Can be held by hand or on stand, especially suitable for sample in EP tube.
B.AC and DC power supply; Can be connected to vehicle adapter
C.Circuit made of SMT process has the features of automatic frequency tracking, automatic amplitude control, thermal protection.
D.Amplitude pole is made of titanium alloy, which is of high strength, high sound speed, good corrosion resistance, high heat resistance, etc.
E.With overloading protection and wide voltage input, it can be used in any country all over the world.
Specification:
|
Frequency Range: |
30 KHz (frequency is auto-tracking) |
|
Max. Output Power： |
150 W (0%-100% continuous adjustable) |
|
Power： |
12-24V/DC, 110V/AC-220V/AC |
|
Vehicle power supply: |
12V |
|
Diameter of ultrasonic probe: |
Ф6 mm (Ф2 mm, Ф3 mm, Ф8 mm optional ) |
|
Sample processing volume： |
5 mL~ 100 mL |
|
Material of Probe: |
Titanium alloy |
|
Size of Main Machine: |
265 mm* Ф42 mm |
|
Packing size: |
33*20*15 (cm) |
|
Gross Weight： |
2.5 kg |
