Features:
- Accepts label core diameters in 1/1.5/3 inches.
- With speed adjustable knobs, speed can up to 10 inches/second.
- Using mechanical touch probe, suitable for translucent and opaque labels, like self-adhesive label, bar codes label, security labels, packaging label, anti-counterfeit labels, hot stamping stickers, stickers, printing patterns and chrome paper etc.
Specifications:
Label Width Range: 0.2”- 3.15” (5-80 mm)
Label Length Range: 0.2”- ∞ (5-∞ mm)
Core Diameter: 1/1.5/3inches
Max. Roll Diameter: 7.8” (200 mm)
Max Dispensing Speed: 10 inches/second
Voltage: AC 100V – 240V, 50Hz /60Hz
Machine Dimensions: 7.28” x 7.87” x6.69”(185 x 200 x 170 mm)
Net weight: 6.1 lbs
Our Tips:
- The machine will not rotate until the speed is adjusted to at least 20.
- This machine is not suitable for labels with perforation line. It is not recommended that you choose this machine if the release liner of your label is thick, hard or easily broke.
- The thickness of the translucent label needs to be thicker than 0.05mm.
|
SKU |
Label Width |
Label Length |
Core Diameter |
Max. OD of Roll |
Counter |
Translucent Labels |
Transparent Labels (thickness 0.03mm) |
|
0.24~5.51 inches |
0.16~7.87 inches |
1~3 inches |
9.84 inches |
✓ |
x |
x |
|
|
0.16~5.51 inches |
0.12~5.91 inches |
1~3 inches |
9.84 inches |
✓ |
x |
x |
|
|
0.24~4.7 inches |
0.16~7.87 inches |
≥0.39 inches |
9.84 inches |
✓ |
✓ |
x |
|
|
0.24~6.3 inches |
0.16~7.87 inches |
≥0.39 inches |
9.84 inches |
✓ |
✓ |
x |
|
|
0.2~3.15 inches |
0.2”- ∞ |
1/1.5/3 inches |
7.88 inches |
x |
✓ |
x |
|
|
0.2~4.7 inches |
0.2”- ∞ |
1/1.5/3 inches |
7.88 inches |
x |
✓ |
x |
|
|
0.2~7 inches |
0.2”- ∞ |
1/1.5/3 inches |
7.88 inches |
x |
✓ |
x |
|
|
0.2~3.15 inches |
0.2”- ∞ |
1/1.5/3 inches |
11 inches |
x |
✓ |
x |
|
|
0.2~4.7 inches |
0.2”- ∞ |
1/1.5/3 inches |
11 inches |
x |
✓ |
x |
|
|
0.2~4.7 inches |
0.2”- ∞ |
1/1.5/3 inches |
11 inches |
x |
✓ |
✓ |
|
|
0.2~7 inches |
0.2”- ∞ |
1/1.5/3 inches |
11 inches |
x |
✓ |
x |
|
|
0.2~3.15 inches |
0.2”- ∞ |
1/1.5/3 inches |
7.88 inches |
✓ |
✓ |
x |
|
|
0.2~4.7 inches |
0.2”- ∞ |
1/1.5/3 inches |
7.88 inches |
✓ |
✓ |
x |
|
|
0.2~4.7 inches |
0.2”- ∞ |
1/1.5/3 inches |
11 inches |
✓ |
✓ |
✓ |
|
|
0.2~7 inches |
0.2”- ∞ |
1/1.5/3 inches |
7.88 inches |
✓ |
✓ |
x |
|
|
0.4~4.3 inches |
0.2~11.8 inches |
1/1.5/3 inches |
7.88 inches |
✓ |
✓ |
✓ |
|
|
0.4~4.52 inches |
0.32~5.11 inches |
≥0.39 inches |
7.88 inches |
x |
✓ |
x |
|
|
0.4~4.52 inches |
0.32~5.11 inches |
≥0.39 inches |
7.88 inches |
✓ |
✓ |
x |
|
|
0.4~4.52 inches |
0.32~5.11 inches |
≥0.39 inches |
7.88 inches |
x |
✓ |
✓ |
|
|
0.4~4.52 inches |
0.32~5.11 inches |
≥0.39 inches |
7.88 inches |
✓ |
✓ |
✓ |
