Specifications
Pipe Size: 1/4"
Flow Aperture: 2.5 mm
Body Material: Stainless Steel
Gasket / Diaphragm / Seal: VITON
Operation Type: Direct Lift Valve
Operation Mode: Normally Closed
Voltage: DC 12V ± 10%
Power rating: 14W
Suitable Media: Air, water, oil, Diesel fuel, kerosene etc.
Operational pressure range: Air/Water/Diesel fuel/kerosene: 0-7 Bar (0 to 101 PSI); Oil: 0-5 Bar(0 to 72 PSI)
Flow capacity: 0.23 gallons per minute (GPM) of water at 60 oF with a pressure drop of 1 PSI
Flow value: 0.23 Cv
Temperature, Minimum: 14 degrees Fahrenheit (-10 degrees Celsius)
Temperature Maximum: 248 degrees Fahrenheit (120 degrees Celsius)
Also available with brass body: Item #USS2-00051.
OVERHEATING WARNING: Not designed for continuous operation(not a 100% duty cycle). While energized, under normal operating conditions, solenoid valve will get HOT. The coil will reach a maximum temperature of about 176°F (80°C), which is fully complied with national standard: JB/T7352-2010. If energized continuously for more than 8 hours the coil may burn.
- Reviews
- Questions
United StatesSolid built
I replaced a 1/4 inch 12 volt value that was far more expensive with the US Solid and I was very pleased that it performed equally as well.
United Statesworks like a charm
Afer getting the correct size, I was able to install and it works fine.
United StatesGood Valve, Poor Tech Support
The overall quality of the valve seemed good, and it worked for my needs however, Tech Support was worse than poor. Could not answer even simplest of questions like: mounting hole diameter and pitch. Turns out to be M 5x 0.8mm. I had to figure it out by trial and error. Tech Support could not tell me MOPD (Mean Operating Pressure Differential). These two pieces of info should have been on a look up chart somewhere. Either there was a language barrier or this was just another imported knock-off that was reverse engineered and copied and no one expected any real technical questions. Very sad...Michael Kalagian, Mechanical Engineer, Geneva, IL.
United StatesWorks great
Delivered sooner than expected and solenoid is very solid.
United StatesBad deal
Nothing on web site said that this item cannot be used with gas. Gasoline eats the boron seal. I discovered this when I opened the box and read the paper inside so I cannot use it for my Kunitz ITV.
