The U.S. Solid USS-HMA01 Moisture Analyzer was designed to provide accurate measurements and fast results. It comes with smart functionalities that allows you to preset and store measuring methods, so you can access the options with ease. The device features a 400W halogen lamp and a premium transducer that delivers fast and accurate results even on low-moisture samples. Compact, practical, and easy to use, this moisture balance is a better choice for every lab.
The USS-HMA01 Moisture Analyzer can preset and store up to 16 groups of measuring methods which will greatly improve measurement convenience. There are also 3 drying modes (Standard, Fast and Soft) and 3 ending modes (Auto, Manual and Timing) to choose from, which will bring great flexibility and excellent adaptability for various samples and testing situations. The cast aluminium enclosure, multi-storey stainless steel heating chamber and the high definition backlit LCD display determine the high quality and excellent experience.
Features:
· 400W halogen lamp;
· HD backlit LCD display;
· Allows up to 16 groups of methods to be preset and stored;
· 3 drying modes: standard, fast, and soft;
· 3 ending modes: automatic, manual, and timing;
· Cast aluminum enclosure;
· Multi-storey stainless steel heating chamber
· 50 sample pans included
Specifications:
Capacity: 110 g
Minimum Weight: 1 g
Readability: 0.005 g (5 mg)
Moisture Readability: 0.1%
Heating Element: Halogen Lamp
Gross Weight: 15.7 lbs
Packaging Dimensions: 13.78*13.78*18.90 inches (35*35*48 cm)
Instruction Manual
Instruction Video
Positioning |
Mainstream |
High-end |
Economical |
|||||||
Weight Readability |
0.005 g |
0.001 g |
0.001 g |
0.001 g |
0.001 g |
0.0001 g |
0.0001 g |
0.01 g |
0.005 g |
0.001 g |
Moisture Readability |
0.1 % |
0.01% |
0.01 % |
0.01 % |
0.01 % |
0.001 % |
0.001 % |
0.1 % |
0.05% |
0.01 % |
High-end strain gauge |
Electromagnetic force |
Strain gauge |
||||||||
Push Button |
Push Button |
5-inch Touch Screen |
7-inch Touch Screen |
7-inch Touch Screen |
7-inch Touch Screen |
7-inch Touch Screen |
5-inch Touch Screen |
5-inch Touch Screen |
5-inch Touch Screen |
|
Calibration |
Manual |
Manual |
Manual |
Manual |
Manual |
Manual |
Manual |
Manual |
Manual |
|
Heater Cover |
Manual |
Manual |
Manual |
Manual |
Automatic |
Automatic |
Automatic |
Manual |
Manual |
Manual |
Data Storage Group |
15 |
15 |
20 |
200 |
200 |
200 |
200 |
20 |
20 |
20 |
Temperature Range |
40℃ - 199℃ |
40 ℃ - 200 ℃ |
40 ℃ - 160 ℃ |
|||||||
Drying mode |
Standard, Fast, Soft |
Standard, Fast, Soft, Step |
Standard, Fast, Soft |
|||||||
Ending mode |
Automatic, Timing, Manual |
|||||||||
Pan size |
Φ90 mm |
Φ100 mm |
Φ100 mm |
|||||||
Interface |
RS-232 |
